Hydraulic System Standing Seam Metal Roof Machine , Door Frame Metal Roofing Machine

Brand Name : JN

Model Number : Customize

Certification : CE ISO

Place of Origin : Hebei, China

MOQ : Negotiable

Price : Negotiable

Payment Terms : T/T, Western Union, L/C

Supply Ability : 50 Sets per month

Delivery Time : about 30 days

Packaging Details : Seaworthy Packing

Material Thickness : 0.3-0.8mm

Working speed : 8 - 25m/min

Automatic : Auto PLC Control Hydraulic

Cutting Blade Material : Cr12

Roller Material : 45# steel

Name : Hydraulic System Rolling Shutter Machine , Door Frame Roll Forming Machine

Contact Now

Hydraulic System Rolling Shutter Machine , Door Frame Roll Forming Machine

Description and Application:

Shutter door forming machine is to produce rolling doors of major equipment, the use of galvanized steel or different colors of color steel or aluminum as a raw material, production of color plate rolling gates brilliant color, do not fade, do not rust, fire cut off, easy deformation, strength 3 times higher than the aluminum door.

Rolling shutters have many applications, including doors for vans, garages, kitchens, schools, prisons and warehouses.

Main Material Used

1. Material: Color steel ,galvanized steel or Aluminum
2. Feeding width:300mm
3. Material thickness:0.8-1.5mm
4. Yield strength:235-450mpa

Technical Parameter:

Main Motor Power	7.5 kw
Hydraulic Station Powder	3 kw
Hydraulic Oil Pump	CE-310
Sprocket	P-25.4mm
Control System	PLC
Yield Strength	235-450Mpa
Diameter of Axis	80mm
Material Roller	#45 steel hard chrome plating
Processing speed	8-12m/min
Frame	30H steel welding
Roller plate thickness	0.3-1.5mm
Use	The machine used to produce all kinds of house, supermarket , garage,etc
Equipment parts	Decolier, main roll forming machine, hydraulic cutter, hydraulic station, PLC electric control system, counter, product supporter

Hydraulic System Standing Seam Metal Roof Machine , Door Frame Metal Roofing Machine
